Giant Revolt X 1

Giant Revolt X 1
  • Color: Cold Night
$3,060.00
$3,599.00
Color:
Cold Night
Please select options
Purchase online and pick up in-store. Orders can take 24 to 48 hrs to be processed. We'll notify you once your order is ready. 10% processing fee applies to any cancelled or modified orders.

Details

Unlock new terrain with this progressive new gravel bike featuring front suspension technology. The lightweight aluminum frame has suspension-adjusted geometry and a rear flip chip that lets you adjust wheelbase and tire clearance for any adventure.

KEY PERFORMANCE FACTORS
Smooth control
Lightweight aluminum frameset is designed specifically for front suspension. With 40mm of travel, the fork absorbs impacts so you can ride smoother and faster over rugged gravel and dirt.

Tuned compliance
Lowered seatstays with smaller diameter tubes absorb road shocks and vibrations. A Contact SL XR D-Fuse handlebar adds more compliance without sacrificing the stiffness needed for cornering, sprinting or climbing.

Adaptable to the terrain
A flip chip on the rear dropout adjusts the wheelbase: short for quicker handling, or long for improved stability at speed. The long setting also allows for larger diameter tires up to 53mm. You can use the included dropper/suspension seatpost for added capabilities, or switch to a proprietary D-Fuse seatpost or traditional 30.9mm round seatpost.

HIGHLIGHTS:
An ALUXX aluminum frameset with suspension-optimized geometry is paired with a purpose-built short-travel (40mm) fork. A flip chip on the rear dropouts allows you to adjust the wheelbase and increase tire clearance up to 53mm.You can use the included dropper seatpost, switch to a proprietary D-Fuse seatpost, or use a traditional 30.9mm round seatpost. A Contact SL D-Fuse handlebar minimizes fatigue by further absorbing shocks and vibrations.

ALUXX ALUMINUM
- Frame material features 6061 alloy with single-butted tubes to produce strong, lightweight framesets for a variety of different bikes and riding styles.

SUSPENSION FORK
- 40mm of front travel expands this bike's capabilities, improving control and reducing fatigue while riding rough roads, gravel and dirt.

FLIP CHIP DROPOUT
- Geometry, wheelbase and rear tire clearance can be adjusted using two-position hardware in the rear dropouts. A longer wheelbase adds stability and increases tire clearance (up to 53mm), while a shorter wheelbase delivers a quicker, more agile ride.

COMPACT ROAD
- A downward sloping top tube (from the head tube to the seat tube) creates smaller front and rear triangles for a lighter, stiffer bike. It also makes it easier for riders of all sizes to have a perfect fit.

D-FUSE TECHNOLOGY
- Proprietary D-shaped handlebar works to dampen vibrations and absorb road shock, resulting in a smooth, compliant ride quality.

SEATPOST ADAPTOR
- New frame design allows you to use the stock dropper seatpost, a proprietary D-Fuse seatpost, or a traditional round 30.9mm seatpost. This lets riders choose the right seatpost for their riding style and terrain.

GIANT TUBELESS SYSTEM
- Integrated Tubeless WheelSystem and tires deliver improved efficiency, comfort and control in the most user-friendly and reliable system.

DISC-BRAKE INTEGRATION
- The frame and fork are engineered specifically for disc brakes, producing reliable braking performance in all weather and road conditions.

OVERDRIVE
- Designed for precise steering performance, this system's oversized headset bearings (1 1/4" lower and 1 1/8" upper) and tapered steerer tube work together to provide optimal steering stiffness and control.

MEGADRIVE
- A massive rectangular down tube and oversized top tube provide superior lateral and torsional steering precision. The precisely engineered, rectangular shaped down tube yields unprecedented steering and pedaling stiffness.

POWERCORE
- A massively oversized bottom-bracket/chainstay area features a threaded, BSA 68 bottom-bracket design. Asymmetric chainstays provide additional stiffness on the driveside and stability on the non-driveside.

Geometry

Sizes:
SmallMediumMedium/LargeLargeX-Large
SHORT | LONG SHORT | LONG SHORT | LONG SHORT | LONG SHORT | LONG
A SEAT TUBE LENGTH (mm) 450 470 490 510 530
B SEAT TUBE ANGLE 73.5° | 73.4° 73.5° | 73.4° 73.0° | 72.9° 73.0° | 72.9° 73.0° | 72.9°
C TOP TUBE LENGTH (mm) 553 560 575 585 600
D HEAD TUBE LENGTH (mm) 100 115 130 145 160
E HEAD TUBE ANGLE 71.0° | 70.9° 71.5° | 71.4° 72.0° | 71.9° 72.0° | 71.9° 72.0° | 71.9°
F FORK RAKE (mm) 45 45 45 45 45
G TRAIL (mm) 76.9 | 80.3 73.5 | 76.8 70.1 | 73.4 70.1 | 73.4 70.1 | 73.4
H WHEELBASE (mm) 1024 | 1034 1026 | 1036 1031 | 1041 1041 | 1051 1057 | 1067
I CHAIN STAY LENGTH (mm) 425 | 435 425 | 435 425 | 435 425 | 435 425 | 435
J BOTTOM BRACKET DROP (mm) 68 | 69 68 | 69 68 | 69 68 | 69 68 | 69
K STACK (mm) 560 576 592 607 621
L REACH (mm) 387 389 393 399 410
M STAND OVER HEIGHT (mm) 736 | 743 755 | 761 772 | 778 790 | 796 808 | 814
N HANDLEBAR WIDTH (mm) 440 460 460 480 480
O STEM LENGTH (mm) 60 70 80 80 80
P CRANK LENGTH (mm) 170 172.5 172.5 175 175
Q WHEEL SIZE 700c 700c 700c 700c 700c
Sizes:
Small5'3" - 5'7"
Medium 5'7" - 5'11"
Medium/Large 5'9" - 6'1"
Large 5'10" - 6'3"
X-Large 6'2" - 6'7"

Specs

Frame ALUXX-Grade Aluminum, 12x142mm thru-axle, disc, flip chip dropout
Fork RockShox Rudy XPLR, 40mm, cartridge damper 12x100mm thru-axle
Rims Giant XCT-1 Disc WheelSystem
Hubs Shimano cup and cone
Spokes stainless
Tires Giant CrossCut Grip 1, 700x45c, tubeless
Bottom Bracket SRAM DUB, threaded
Crankset SRAM Rival D1 DUB, 40t XS:170mm, S:170mm, M:172.5mm, M/L:172.5mm, L:175mm, XL:175m
Shifters SRAM Rival 1, 1x11
Rear Derailleur SRAM Rival 1
Cassette/Freewheel SRAM Rival, 11-speed, 11x42
Chain SRAM PC-1130
Brakes SRAM Rival 1 hydraulic, SRAM PaceLine rotors [F]160mm, [R]160mm
Brake Levers SRAM Rival 1, left lever dropper switch
Handlebars Giant Contact SL XR D-Fuse, 16-degree flare XS:44cm, S:44cm, M:46cm, M/L:46cm, L:48cm, XL:48cm
Tape/Grips cork tape with gel
Stem Giant Contact, 8-degree XS:50mm, S:60mm, M:70mm, M/L:80mm, L:80mm, XL: 80mm
Seatpost Postmodern, dropper, 30.9mm with 25mm of suspension XS:365mm / 75mm drop S:415mm / 100mm drop M:415mm / 100mm drop M/L: 415mm / 100mm drop L:415mm / 100mm drop XL: 415mm / 100mm drop
Saddle Giant Approach
Pedals Sold separately

* Subject to change without notice.

Part Numbers

Option UPC MPN
Cold Night / Medium/Large 04712878857308 2302026126
Cold Night / Large 04712878857315 2302026127
